Key Features
- 304-grade stainless steel canopy for outdoor applications
- 3-speed controls up to 1,200 CFM
- 6W LumiLight LED dual-level lighting
- High-airflow baffle filters that are dishwasher safe and ensure a lifetime of exceptional performance
- 10-inch round vertical and horizontal ducting
- 32-inch depth to capture maximum smoke from your outdoor grill
- A welded and polished body ensures a high quality, seamless appearance
- This hood has the ability to vent either out the top or out the back
- Optional Extension Duct Cover Kit (sold separately)
Description
Downloads
Please select from the Zephyr brochures and other documents below to learn more about this item.
Dimensions
All dimensions below are measured in inches and represent the product when fully assembled.
Width
36"
Depth
32"
Height
18"
Weight
84 Lbs
Specifications
Specifications, data and other product details are listed below for this Zephyr item.
UPC Code
646328010583
Manufacturer
Zephyr
Class
Premium
Exterior Material
Stainless Steel
Exterior Stainless Grade
304 Stainless Steel
Primary Color
Stainless Steel
Width Range
30 - 39 Inches
Depth (Front to Back)
32 Inches
Vent Mounting Type
Wall Mount
Hood Style
Canopy
Blower Type
Internal
Venting Type
Ducted
CFM
1,200 CFM
Fan Speed
3
Volts
120 Volts
Approved For Outdoor Use
Yes
Made in the USA
No
Commercial Grade
No
Extra Features
N/A
Warranty
Zephyr warrants this product with three (3) years of parts and one (1) year labor. Labor is included for one (1) year. Refer to manufacturers manual for full warranty details.
